Super35 Cinema Prime

Super35 Cinema Prime

by Meike USA
$649.00 - $699.99
$699.99
$649.00 - $699.99
$699.99
Focal Length: 12mm T2.5
Lens Mount: Canon EF

Specifications:

MK-S35 12mm T2.5 MK-S35 18mm T2.1 MK-S35 25mm T2.1 MK-S35 35mm T2.1 MK-S35 50mm T2.1 MK-S35 75mm T2.1 MK-S35 100mm T2.1
Lens Mount: PL/EF PL/EF PL/EF PL/EF PL/EF PL/EF PL/EF
Min Focal Dist: 20cm 25cm 35cm 48cm 60cm 70cm 90cm
Image circle: 28.2mm 33.5mm 33.6mm 33.6mm 33.6mm 33.6mm 33.6mm
Filter Thread: ø86 ø77 ø77 ø77 ø77 ø77 ø77
Outer Diameter 90mm 80mm 80mm 80mm 80mm 80mm 80mm
Structure: 17 Elements in 10 Groups 15 Elements in 10 Groups 13 Elements in 10 Groups 12 Elements in 10 Groups 12 Elements in 9 Groups 13 Elements in 11 Groups 13 Elements in 7 Groups
Focal Length: 12mm 18mm 25mm 35mm 50mm 75mm 100mm
Aperture Range: T2.5-T22 T2.1-T22 T2.1-T22 T2.1-T22 T2.1-T22 T2.1-T22 T2.1-T22
Iris Blades: 10 10 10 11 11 13 12
Gear Mod: M0.8 M0.8 M0.8 M0.8 M0.8 M0.8 M0.8
Focus Rotation: 270 Degree 270 Degree 270 Degree 270 Degree 270 Degree 270 Degree 270 Degree
Dimensions PL (Ø x L) φ85.5 × 103mm φ85.5 × 93.4mm φ85.5 × 96.7 mm ø85.5 × 98.5 mm φ85.5 × 98.5 mm φ85.5 × 98.5 mm φ85.5 × 98.5mm
Dimensions EF (Ø x L) φ85.5 × 111mm φ85.5 × 101.4mm φ85.5 × 104.7mm ø85.5 × 106.5 mm φ85.5 × 106.5mm φ85.5 × 106.5mm φ85.5 × 106.5mm
Weight (PL/EF) 880g / 880g 849g / 843g 927g / 923g 972g / 997g 972g / 997g 990g / 1015g 945.6g / 943.7g
FOV: Diagonal: 104.5 °
Horizontal: 97.1°
Vertical: 61.1 °c
 Diagonal: 76.6 °
Horizontal: 63.2°
Vertical: 45.5 °c
 Diagonal: 64.2°
Horizontal: 53.2°
Vertical: 41°
 Diagonal: 48.2°
Horizontal: 40.8°
Vertical: 27.8°
 Diagonal: 31.7°
Horizontal: 25.2°
Vertical: 17.2°
 Diagonal: 23.9 °
Horizontal: 19°
Vertical: 14.6 °
 Diagonal: 15.3 °
Horizontal: 12.6°
Vertical: 8.6 °
